Spped Control of Three Phase Slipring Induction Motor Using Static Scherbius Slip Power Recovery Control Scheme

Description

1 HP Induction Motor Slipring Type for demonstration of speed variation of induction motor. Ammeter/Voltmeter provided alongwith the set up.

Electronic Controller includes Power Supply, Firing, Circuit, Contactor, SCR Bridge Inverter and 6 diode bridge converter for rotor side. DV/DT protection for Thyristors included.
